Iota DLS-75 75 Amp Power Converter Battery Charger, DLS-75

The Iota DLS-75 Power Converter/Battery Charger converts nominal 108-132 VAC to 13.4 VDC for both DC load operation and 12V battery charging. As a power supply, it can operate a nominal 12 VDC load up to 75 amps. As a battery charger, it delivers its full-rated current when the battery capacity falls low, then drops the current to provide a float charge as the battery nears full capacity.

Features

• Tightly controlled regulation for operating a nominal 12 VDC load
• Voltage set to deliver maximum current for the necessary period to minimize stress on the battery caused by heating of its cells
• Automatically drops the current to float-charge the battery and prevent self-discharge of the cells

Specifications

• Input voltage: 108-132 VAC
• Input frequency: 50-60 Hz
• Output voltage: 13.4 VDC
• Output amperage: 75 Amps
• Manufacturer part number: DLS-75
