Paneltronics Breaker 40 Amps A-Frame Magnetic Waterproof 206-057S
$34.95
In stock
SKU
JMS178079
PANELTRONICS BREAKER 40 AMPS A-FRAME MAGNETIC WATERPROOF
Panel Seal / Waterproof "A" Frame Magnetic Circuit Breakers
Specifications
- Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
- Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers
- UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada
- Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
- Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
Specifications
- Handle Color: Metal with Silicon rubber seal
- Maximum Amperage: 50 Amps
- Maximum Voltage/AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)
- Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage
- Electrical Hardware: Screw 10-32 x 3/8" pan combo head (P/N 197-188)
- Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker) Lockwasher 1/2" internal tooth (supplied with circuit breaker)
- Optional Boot: Black silicone rubber (P/N 048-015)
| UPC Code | 602290201466 |
|---|---|
| Manufacturer Part Number | 206-057S |
| Manufacturer | Paneltronics |
