Nobeltec Furuno Radar Plus Pack f/Trident & Catch - Digital Unlock Code Only HA-0040

Furuno Radar Plus Pack f/Trident & Catch - Digital Unlock Code Only

Integrate TimeZero software with best-in-class Furuno radars and MFDs

The Furuno Radar Plus Pack allows the user to make the most of compatible FURUNO radars and MFDs. Combine FURUNO hardware with Nobeltec TimeZero for a powerful navigation solution.

The commercial-grade FAR 2xx7 series of radars can be integrated with Nobeltec TimeZero software, responding to professional user needs.
Recreational users on the other hand, will be impressed by the advanced integration available with the acclaimed NavNet 3D and TZtouch MFDs. The FURUNO DRS (Digital Radar Sensors) that are on the NavNet network can be fully integrated with Nobeltec TimeZero software, enabling the display, control and overlay of the radar from within the software.

Nobeltec TimeZero software connects to the NavNet network and receives navigation data directly from the network.

Combining the NavNet and TimeZero software systems results in an extremely fast and user-friendly solution.

Features
When the FURUNO Radar Plus Pack is added to your Nobeltec TimeZero software (Trident, SportFishing or Catch), a range of functionalities are unlocked, between your FURUNO radar or MFD and software.

Nobeltec TimeZero navigation software can be connected to a Furuno NavNet3D or TZtouch network allowing full control of the DRS radars (with an MFD present on the network). This means that you can display the radar image directly in TimeZero software, enjoy full control of the software from your software, and overlay the radar image on your charts. Radar overlay is an effective safety tool that allows you to understand your surroundings in relation to your current position.

When Nobeltec TimeZero is connected to a NavNet3D network, the following capabilities are enabled:

• Reception of all navigation information (Position, COG/SOG, Heading, Wind, AIS, etc.) from the NavNet3D Network

• Real-Time synchronization of the Active Route among the PC and every
• NavNet3D MFD display on the network

• Exchange Routes and Waypoints from the PC to NavNet3D MFD(s) over the network

• Share charts between the NavNet3D and Nobeltec TimeZero software

• Enable the Chart Server for the NavNet3D MFD(s)

• View and control the DRS Radar (*)

When Nobeltec TimeZero is connected to a NavNet TZtouch network, the following capabilities are enabled:

• Reception of all navigation information (Position, COG/SOG, Heading, Wind, AIS, etc.) from the NavNet TZtouch Network

• Real-Time synchronization of the Active Route between the PC and every
• TZtouch MFD display on the network

• Share charts between the NavNet3D and Nobeltec TimeZero software

• Display and control of the DRS Radar (*)

(*) MFD must be present on the network

The Plus Pack also enables connection to a Furuno FAR2XX7 series radar when this optional Furuno Radar Plus Pack is unlocked. These commercial-grade radars have an Ethernet connection that makes the connection to Nobeltec TimeZero possible, and enables the following capabilities:

• View and control the Furuno 2XX7 Radar from your PC

• Acquire and display ARPA targets

• Receive Position, COG/SOG, Heading data from the FAR2XX7 Network
