Garmin echo 150 Dual Beam Fishfinder TM/Trolling Transducer 010-00951-00

echo 150 - Compact Easy-to-use Dual-Beam Fishfinder

With dual-beam technology at a single-beam price, echo 150 is the sport fisherman's dream. With 200 watts (RMS) power, you can accurately scan to depths of 1,300 feet in freshwater. In shallower water, a viewing angle of up to 120 degrees lets you see fish well beyond the sides of your boat. And to take even more guesswork out of the equation, Garmin's HD-ID target tracking technology provides you with better separation and definition of images on a crisp 4-inch grayscale display. The included quick-release tilt/swivel mount and versatile transom/trolling motor-mount transducer make installation a snap. Plus, echo 150's compact design will keep it out of your way all day long - even on smaller craft.

Product Features and Specifications

• Garmin HD-ID technology for excellent fish arch presentation and bottom tracking

• Display: 4-inch diagonal / 8-level grayscale

• Resolution: 256 x 160, FSTN

• Quick release mount with tilt and swivel included in the box

• Flush mount capable with optional flush mount kit

• Capable of displaying depth and water temperature numbers

• Transmit power: 200W (RMS) / 1,600W (peak to peak)

• Cone angle: 60 degrees/120 degrees

• Frequency: 200/77 kHz

• Depth: 1,300 ft (freshwater) / 500 ft (saltwater)

• Waterproof (IEC 60529 IPX7)

• 10 - 20V input
  Frequency = 200/77 kHz | Resolution (VxH) = 256 x 160 | Screen Size = 4" | Speed/Temp = NONE | Transducer Type = NONE | Waterproof Rating = Waterproof | Watts RMS - Max = NONE
