Garmin echo 100 Single Beam Fishfinder TM/Trolling Transducer 010-00950-00

echo 100 - Affordable Easy-to-use Single Beam FishfinderThe echo 100 fishfinder brings a new level of fishfinding capability to the budget-minded buyer. Thanks to Garmin's HD-ID target tracking technology, you'll see enhanced separation and definition of images on echo 100's fast-refreshing, 4-inch grayscale display. The single-beam (200kHz) transmitter with 100 watts (RMS) of sonar power lets you scan to depths of up to 600 feet1 - ample for most freshwater lakes. echo 100's compact design makes it the perfect companion for even small craft. Plus, its quick-release tilt/swivel mount and versatile transom/trolling motor-mount transducer are included in the box to make installation a snap.

Product Features and Specifications

• Garmin HD-ID technology for excellent fish arch presentation and bottom tracking

• Display: 4-inch diagonal / 8-level grayscale

• Resolution: 256 x 160, FSTN

• Quick release mount with tilt and swivel included in the box

• Flush mount capable with optional flush mount kit

• Capable of displaying depth and water temperature numbers

• Transmit power: 100W (RMS) / 800W (peak to peak)

• Cone angle: 60 degrees

• Frequency: 200 kHz

• Depth: 600 ft (freshwater) / 300 ft (saltwater)

• Waterproof (IEC 60529 IPX7)

• 10 - 20V input
  Frequency = 200 kHz | Resolution (VxH) = 256 x 160 | Screen Size = 4" | Speed/Temp = NONE | Transducer Type = NONE | Waterproof Rating = Waterproof | Watts RMS - Max = NONE
