BLUE SEA 7702100 ML SOLENOID 12V 500A WI

BLUE SEA 7702100 ML SOLENOID 12V 500A WI 7702100 ML Solenoid 12V 500A with Manual Control & Deutsch Connector 500 Amp magnetic latching switch provides high amperage switching under load, manually or from remote locations. Features: Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing LED output to remotely indicate switch state - requires optional LED 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance 7/8" (22 mm) stud length accepts multiple cable terminals Label recesses for circuit identification Silver alloy contacts provide high reliability for switching live loads Specifications: Control Circuit Connection: Deutsch DTM Nominal Voltage: 24VDC Coil Function: Bi-Stable Mounting: #10 Amperage Operating Current Continous: 0mA Terminal Stud Torque: 140 in-lb (15.82 Nm) Control Circuit Voltage: 18-32VDC Continuous Rating: 500A Intermittent Rating: 700A (5 min) Cranki
